Guide TE421 400x300 Thermal Monocular

The TE Series Handheld Thermal Imaging Monocular is your compact and reliable night vision solution. Designed with a 400x300 infrared detector and a 25mm lens, it delivers a powerful detection range of up to 1400 yard. Its 0.32'' AMOLED 800×600 ensures clear infrared image viewing without eye strain.

Perfect for extended use, this pocket-sized device offers up to 1 hour of operation with just a quick 10-minute charge. Lightweight, portable, and efficient, the TE Series is the ultimate thermal monocular for outdoor enthusiasts and night hunters.

SHARP & LIGHTWEIGHT

• 400×300@12μm Sensor Resolution
• 1400 yd Detection Range
• 0.32'' AMOLED 800×600 full-color screen
• One-button control for smooth operation
• 25mm; F1.0 Focal length
• 25Mk NETD

Sensor
Type: Uncooled VOx Infrared Detector, 8 to 14μm
Resolution: 400×300@12μm
NETD: 25mK
Frame rate: 50Hz

Lens
Objective lens: 25mm, F1.0
Field of view: 11°×8.2°
FOV m@100m: 19×14
Magnification: 1.9x~7.6x
Detection range: 1300m/1400yd
Focus: Manual

Display
Display type: 0.32'' AMOLED 800×600
Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia

Eyepiece
Eye relief: 25mm; Diopter: -5 to +5; Zoom: 14x

Hardware
WIFI: 2.4G, 5G
Interface: USB Type-C, Support charging
Others: Microphone, Bluetooth

System
Recording function: Photo/Video (Audio recording included)
Memory capacity: 16GB

Power
Battery type: Built-in battery
Operating time: 5 hours (Support 20W quick charging)

Environmental
Operating temp.: -20°C to 50°C / -4°F to +122°F
Encapsulation: IP67

Physical
Weight (g/oz): 295/11.11
Size (mm/in): 47×47×155/1.85×1.85×6.10
Standard: Device, Lens cover, Eye mask, Wrist strap, Quick charging adapter, USB Type-C cable, Quick use guide, Safety Information Manual, Warranty card
Optional: Bluetooth remote control
